RGS 85 cable tray, perforated, heavy, height = 85 mm

cable tray, heavy-duty, perforated, head shape suitable for positive locking covers, with longitudinal and lateral reinforcing rims reducing bottom deflection, certified including electrical conductivity according to DIN EN 61537

Assembly Instruction

Do not walk upon!

Continously hot galvanized (Sendzimir process) (DIN EN 10346)

	height	width	length	t material thickness	A cross section area	Q_SKdistributed load control cable	weight
RGS 85-10S	85 mm	100 mm	3000 mm	1,50 mm	82 cm²	0,12 kN/m	9,84 kg
RGS 85-20S	85 mm	200 mm	3000 mm	1,50 mm	167 cm²	0,25 kN/m	12,84 kg
RGS 85-30S	85 mm	300 mm	3000 mm	1,50 mm	252 cm²	0,38 kN/m	16,14 kg
RGS 85-40S	85 mm	400 mm	3000 mm	1,50 mm	337 cm²	0,51 kN/m	19,45 kg
RGS 85-50S	85 mm	500 mm	3000 mm	1,50 mm	422 cm²	0,63 kN/m	22,75 kg
RGS 85-60S	85 mm	600 mm	3000 mm	1,50 mm	507 cm²	0,76 kN/m	26,07 kg
