Shuttering unit, levellable, quadrangular, in floor boxes or cable duct mounting cover, consisting of a sendzimir galvanized steel sheet frame, an internal levelling device including levelling bases and cover. As concealed shuttering for quadrangular installation units, sandable and heat resistant. Suitable for installation in cast asphalt/hot asphalt or terrazzo.
Assembly Instruction
Continously hot galvanized (Sendzimir process) (DIN EN 10346)
| height | HminMinimum installation height | N levelling range | width | length | weight | ||
|---|---|---|---|---|---|---|---|
| UNSKH 260V-100S | 96 mm | 100 mm | 55 mm | 259 mm | 259 mm | 1,53 kg | |
| UNSKH 260V-155S | 96 mm | 155 mm | 70 mm | 259 mm | 259 mm | 2,64 kg |
