UEKD V E stainless steel hinged cover unit, triple, angular

Quadrangular cartridge made of stainless steel sheet with hem. As a cartridge installation frame with inlay cartridge, cable outlet, floor-level cable outlet, self-closing opening lever and rubber seal. For mounting on top of levelling devices in floor boxes, assembly covers and double or hollow floor openings. To accommodate up to 3 mounting boxes equipped with up to 9 suspension bracket installation devices or 12 installation devices of 45x45 mm. Suitable for rooms with dry and damp-cleaned floor covers. Designed for office traffic loads.

Please mind the technical information in chapter planning.

Assembly Instruction

dry-cleaned

Stainless steel, according to ASTM 304 / BS 304 S 3 / Rubber

	height	H_minMinimum installation height	width	length	E fitting dimension	depth	P_maxMaximum load	IP_nIP protection level in unused condition	IP_gIP protection level in used condition	weight
UEKD 15-V E	19 mm	85 mm	258 mm	258 mm	261 x 261 mm	12 mm	2 kN	IP 30	IP 20	1,8 kg
UEKD 25-V E	29 mm	95 mm	258 mm	258 mm	261 x 261 mm	22 mm	2 kN	IP 30	IP 20	2 kg
UEKD 35-V E	39 mm	105 mm	258 mm	258 mm	261 x 261 mm	32 mm	2 kN	IP 30	IP 20	2,2 kg
UEKD 45-V E	49 mm	115 mm	258 mm	258 mm	261 x 261 mm	42 mm	2 kN	IP 30	IP 20	2,4 kg
